Router Accessories

Precision Router Table Set Up Bars
Set of 7

Kreg Precision Router Table Setup Bars make adjustments to router tables, shapers and table saws very simple and very precise. Unique design straddles the router bit or saw blade to allow for more precise height adjustment.
›See more product details

×

Precision Router Table Set Up Bars - Set of 7

Kreg Precision Router Table Setup Bars make adjustments to router tables, shapers and table saws very simple and very precise.

More precise height adjustments

Unique design straddles the router bit or saw blade to allow for more precise height adjustment.

Test the depth

Step on the top edge of each setup bar acts as a gauge to test the depth of your completed cuts. Step on the end of each setup bar used to test the fence depth of a tablesaw blade or router bit.

Soft aluminum designed to prevent damage

Made from a soft aluminum designed to prevent damage to your router bit or saw blade if contact is made during setup.

What's Included

Set includes 7 setup bars stored in a portable case that protects the bars and makes it easy for woodworkers to locate the correct bar for their application.

Close

• Unique design straddles the Router Bit or saw blade to allow for more precise height adjustment
• Step on the top edge of each setup bar acts as a gauge to test the depth of your completed cuts
• Step on the end of each setup bar used to test the fence depth of a table saw blade or Router Bit
• Made from a soft aluminum designed to prevent damage

Brass Bars

These Solid Brass Bars allow you to accurately determine the proper depth of your cuts, fence to cutter distances, material thickness and more without the use of tape measures or calipers. The brass bars also prevent damaging the carbide on the router bit. The brass bars can be stacked to get measurements from 1/8" to 1-7/16".

Features:

• Solid Brass Bars
• prevent damaging the carbide on the router bit
• can be stacked to get measurements from 1/8" to 1-7/16"

The set Includes:

• 1 ea. 1/8" Square x 4" Long Brass Bar
• 1 ea. 3/16" Square x 4" Long Brass Bar
• 1 ea. 1/4" Square x 4" Long Brass Bar
• 1 ea. 3/8" Square x 4" Long Brass Bar
• 1 ea.1/2" Square x 4" Long Brass Bar

FITFINDER 1/2 Gauge

The FITFINDER 1/2 Gauge allows you to find the 1/2 thickness of any material up to 3" thick. Create perfectly fitting joints with zero guesswork, set fences and transfer cutting depths instantly—all with no math or measuring.
›See more product details

No math or measuring required!

1. Match the material's thickness - Place material under P2, then lower P2 so that it rests on top of the material.
2. Find the 1/2 point - The bottom of P3 automatically adjusts to exactly 1/2 the thickness of the material.
3. Transfer measurement - Lock in the measurement and use the FITFINDER to set cutting depths and fences.

Includes:

• 1/2 Gauge

×

FITFINDER 1/2 Gauge

The FITFINDER 1/2 Gauge allows you to find the 1/2 thickness of any material up to 3" thick. Create perfectly fitting joints with zero guesswork, set fences and transfer cutting depths instantly—all with no math or measuring.

No Math or Measuring Required.

1. Match the material's thickness -
   Place material under P2, then lower P2 so that it rests on top of the material.
2. Find the 1/2 point -
   The bottom of P3 automatically adjusts to exactly 1/2 the thickness of the material.
3. Transfer measurement -
   Lock in the measurement and use the FITFINDER to set cutting depths and fences.

Set Fences for Resawing

Set fence position and resaw material on the bandsaw with zero guesswork.

Center Stock on the Lathe

Find the center of stock and mount material on the lathe for safer spindle turning.

Set Precise Cutting Depths

Lock in the measurement and transfer to the router or table saw to set cutting depth for flawless lap joints.

Center Router Bits

Quickly and accurately find the halfway point of material.

Router Depth Gauge

This aluminum Router Depth Gauge makes router set up fast, easy and simple. You simply set the Router Bit Depth Gauge across your cutter (router bit) and adjust the router bit to the required setting. The aluminum Router Depth Gauge is clearly marked in inches. The Router Depth Gauge is designed for setting cutter depths from 1/8” to 1” in 1/16” increments.

Features:

• Set router bits to desired depth of cut.
• Measurements marked in 16ths - 1/8" through 1"
• No more guessing at the depth to cut.
• No more missed cuts because the bit was set to deep.

6" Digital Multi Gauge

Set the heights of router bits and saw blades with greater accuracy! This 3-in-1 digital router combines the functions of three tools: a depth gauge, height gauge and thickness gauge. It is a metal rule with a Super Large LCD display, housed in a heavy-duty polycarbonate frame which allows it to stand freely.
›See more product details

×

6" Digital Multi Gauge

Set the heights of router bits and saw blades with greater accuracy! This 3-in-1 digital router combines the functions of three tools: a depth gauge, height gauge and thickness gauge. It is a metal rule with a Super Large LCD display, housed in a heavy-duty polycarbonate frame which allows it to stand freely. The measuring range is 0-6", with a router depth of 0-3.10" and a slot depth of 2.90". It features buttons for on/off as well as zero set functions, and it easily switches readings from inches to metric to fractions at a touch. Two hardened steel measuring anvils (flat and point) are included.

Features

• 0-6" full range digital gauge: height, depth and welding thickness
• 3-way measuring: horizontal, vertical, 90° angle
• 3-way reading: inch, inch fractional, metric
• Accurate to within 0.001" per 1"
• EZ view with super large LCD display
• 3 angles on gauge body: 70°, 80°, 90°
• Heavy-duty polycarbonate frame for free-standing measuring
• Hardened steel measuring anvils:flat and one with a point
• Locks for accuracy
• Operates on one 3V CR2032 battery (included)

Includes:

• 1 ea. 6" Digital Multi Gauge
• 1 ea. 3V CR2032 battery

Close

Features:

• 0-6" full range digital gauge: height, depth and welding thickness
• 3-way reading: inch, inch fractional, metric
• Accurate to within 0.001" per 1"
• EZ view with super large LCD display
• 3 angles on gauge body: 70°, 80°, 90°
• Hardened steel measuring anvils:
  flat and one with a point
• Locks for accuracy
• Operates on one 3V CR2032 battery (included)

Depth Gauge

With the Trend self standing, depth gauge, it has never been easier to accurately set the height of router bits and saw blades. The steel rule has dual metric and imperial scale, is accurate to 1/32" and offers a range of measurement from 0 to 3-1/8".

Features:

• Horizontal and vertical measuring
• Self standing
• 2-3/8-Inch wide
• Accurate to 1/32-Inch
• Unique cam lever lock
• Dual metric and imperial scale
• Range of measurement from 0 to 3-1/8"

Includes:

• 1 ea. Depth Gauge

Muti-Max Shop Gauge

The Multi-Max is two depth gauge measuring systems, a chisel angle checker and drill point gage in one easy to use tool.
›See more product details

×

Muti-Max Shop Gauge

The Multi-Max is two depth gauge measuring systems, a chisel angle checker and drill point gage in one easy to use tool.

Features

• Drill Point Gauge -Properly sharpened drill bits save time and money. Let the Multi-Max be your guide to a perfectly sharpened drill bit every time.
• Chisel Angle Gauge -End the guess work when sharpening chisels. Place your chisel into the Multi-Max chisel checker for the optimum chisel angle.
• Depth Gauge - Easily check the depth of grooves, dados, holes, material thickness and much more with Multi-Max. Stainless steel rule with deeply etched markings are easy to read and will never wear off.
• Router Bit Depth Gauge - Set the depth / height of router bits accurately. Place the the Multi-Max on the base of the router or router table top and raise the bit to match the dept / height you need.
• Height Gauge - Check heights up to 3'. Uses the same stainless steel rule as the dept gauge. Calibrated in inch and metric unties.

Close

5 Measuring gauges in one:

• Drill Point Gauge
  Let the Multi-Max be your guide to a perfectly sharpened drill bit every time
• Chisel Angle Gauge
  End the guess work when sharpening chisels. Place your chisel into the Multi-Max chisel checker for the optimum chisel angle
• Depth Gauge
  Easily check the depth of grooves, dados, holes, material thickness and much more
• Router Bit Depth Gauge
  Set the depth / height of router bits accurately
• Height Gauge
  Check heights up to 3'

Snap Depth Gauge

Measure depths from 0 to 4" with inch, metric or fraction readout modes! Spring loaded travel provides accuracy to 0.001". Check the depth of slots, dovetails, mortises,dadoes and more. Quickly quantify table saw run out and measure the flatness of your blade. Interchangeable 1" and 2" measuring bars included.

Features:

• Measure depths from 0 to 4"
• inch, metric or fraction readout modes
• Spring loaded travel provides accuracy to 0.001"
• Check the depth of slots, dovetails, mortises,dadoes and more
• Interchangeable 1" and 2" measuring bars included.

6" Depth Gauge

Has 2-3/8" wide hardened steel base. Spring tension nut eases depth and angle measuring by securing rule in milled slot at 90° to base. Permits easy setting of protractor angle to 30°, 45° and 60° settings on one side. 6" etched stainless steel rule graduated in 64ths and mm on the other side.

Features:

• 2 3/8" wide hardened steel base
• Spring tension nut
• 6" Etched stainless steel rule
• Graduated in 64ths and mm on other side

Includes:

• 1 ea. 6" Depth Gauge

Thickness Gauge

Just “pinch” your wood to read its thickness - from 1/16” to 2” in 1/32” increments. The expanded rear scale is easily read, and includes preset holes at 1/4” intervals for use as a go-no-go gauge, a handy feature for repetitive surface planning or checking turning diameters.

Features:

• 1/16” to 2” in 1/32” increments
• Easy to read scale
• Includes preset holes at 1/4” intervals

Includes:

• 1 ea. Thickness Gauge

EZ Set Router Bit Set Up Tool for Freud® Router Bits

With the new Easy Set for Freud® router bits you can position your router bit perfectly the first time, every time, in any thickness of wood - from 23/32" (3/4" plywood) to 1-3/16" thick stock.

Features:

• Position your router bit perfectly the first time
• Adjusts from 23/32" to 1-3/16"
• Special compressed plastic that will not distort
• Set the exact height of eight different router bit profiles

Note: Works with selected Freud® router bits only.
